Standard
|
IEEE 802.11b/802.3
|
|
Modulation Technique
|
DBPSK for 1Mbps; DQPSK for 2Mbps; CCK for 5.5/11Mbps
|
|
Frequency Band
|
2.400-2.483 GHz
|
|
Antennas
|
9.8 dBi Antenna
|
|
Interface
|
One RJ45 10Base T connector
|
|
Number of channels
|
11 Channels (North America)
|
|
Transmission Power
|
20dBm
|
|
Receiver-Sensitivity
|
-83dBm for 11Mbps
|
|
Data Rate
|
11/5.5/2/1 Mbps
|
|
Coding
|
1,2 Mbps: 11 chip/bit Barker Coding
5.5,11 Mbps: Complementary Code Keying
|
|
OS Compatible
|
Windows 98/ME/NT/2000/XP
|
|
Current Drain
|
<750mA @ 5Vdc
|
Security
|
WEP 64-bit, 128-bit
|
Managment Interface
|
Local-USB; Remote-SNMP, DHCP client, Web server
|
Temperature
|
0 ~ +55°C for operation; -20 ~ +65°C for Storage
|
Power Adapter
|
90 ~ 264 Vac input, 5Vdc output
|
CPE Enclosure
|
6x6x4 inches NEMA Enclosure
|
