 23dBm Radio+17dBi Antenna = 40dBm |
 23dBm Radio+15dBi Antenna = 38dBm |
 23dBm Radio+11dBi Antenna = 34dBm |
| Standard | IEEE 802.11b/802.3 |
| Modulation Technique | DBPSK for 1Mbps; DQPSK for 2Mbps; CCK for 5.5/11Mbps |
| Frequency Band | 2.400-2.483 GHz |
| Antennas | Embedded Gain Adjustable 11dBi/15dBi/17dBi Antenna |
| Enclosure | 6x6x4 inch NEMA 4 Rated Enclosure For Outdoor Applications. |
| Interface | One RJ45 10Base T connector |
| Number of channels | 11 Channels (North America) |
| Receiver-Sensitivity | -83dBm for 11Mbps |
| Radio TX Power | Total 40dBm/38dBm/34dBm with antenna |
| Data Rate | 11/5.5/2/1 Mbps |
| Coding | 1,2 Mbps: 11 chip/bit Barker Coding 5.5,11 Mbps: Complementary Code Keying |
| OS Compatible | Windows 98/ME/NT/2000/XP |
| Security | WEP 64-bit, 128-bit | Managment Interface | Web server | Temperature | 0 ~ +55°C for operation; -20 ~ +65°C for Storage | Power Adapter | 90 ~ 264 Vac input, 12Vdc output |
